Hi Point C9 Disassembly/Reassembly for Cleaning

Published on August 26, 2011
Duration: 12:56

This video provides a detailed, step-by-step guide to disassembling and reassembling the Hi-Point C9 pistol for cleaning and maintenance. It covers safety checks, slide removal, striker assembly breakdown, frame component removal, and the reassembly process, emphasizing proper tool usage and part alignment. The host highlights the firearm's simple design and offers practical tips for a successful cleaning.

Quick Summary

To safely disassemble a Hi-Point C9, first remove the magazine and visually inspect the chamber to ensure it is unloaded. Then, lock the slide to the rear to expose the roll pin, which is removed using an armorer's block and roll pin punch. The slide can then be lifted off the frame.

Chapters

  1. 00:00Introduction and Safety Check
  2. 00:51Slide Removal
  3. 02:15Slide Disassembly
  4. 03:47Frame Disassembly
  5. 05:53Reassembly of Frame and Slide
  6. 08:40Final Reassembly and Function Check

Frequently Asked Questions

What are the first steps for safely disassembling a Hi-Point C9?

Before beginning disassembly, always ensure the firearm is unloaded. Remove the magazine, then visually inspect the chamber to confirm it is clear. This safety check is crucial before proceeding with any maintenance or cleaning procedures.

How do you remove the slide from a Hi-Point C9?

To remove the slide, lock it to the rear to expose the roll pin. Use an armorer's block and a roll pin punch to drift the pin out. Once the pin is removed, pull the slide back and up to lift it off the frame.

What tools are recommended for Hi-Point C9 disassembly?

Recommended tools include an armorer's block to support the frame and a roll pin punch for safely removing the slide retaining pin. A Phillips head screwdriver is also needed for removing the grip panels.

What is the Hi-Point C9's operating system?

The Hi-Point C9 operates on a straight blowback system. This mechanism is known for its simplicity and uses fewer moving parts compared to many other handgun designs, making maintenance straightforward.
